10000psi Recloseable Circulating Sleeve Circulating Valve For Drill Stem Testing Service

Name: 10000psi Recloseable Circulating Sleeve Circulating Valve For Drill Stem Testing Service
Brand: ZZ TOP OIL TOOLS
Price: 1 USD

China 10000psi Recloseable Circulating Sleeve Circulating Valve For Drill Stem Testing Service wholesale

Brand Name : ZZ TOP OIL TOOLS

Model Number : 5" Recloseable Circulating Valve

Certification : ISO, API

Place of Origin : China

MOQ : 1 set

Price : USD 1-10000/set

Payment Terms : L/C, T/T, D/P

Supply Ability : 10 set/month

Delivery Time : 30-50 days

Packaging Details : Pollywood

Product : Recloseable Circulating Valve

Type : APR Tools

Size : 5 inch

Working Pressure : 10000psi

Application : Oil Well Downhole Testing Service

Connection : IF, EUE , CAS

Working Condition : Oil & Gas & H2S service

Working Temperature : Up to 425oF

Contact Now

Recloseable Circulating Valve For Drill Stem Testing Service

The Recloseable Circulating Sleeves are assembled as part of tubing string to establish communication between the tubing string and the casing annulus for single or multiple-tubing string completions.

The Reclosable Circulating sleeves are annulus pressure operated without use of a wireline or coiled tubing tools, features an internal sliding sleeve which seals against the circulating ports. The sleeve is held in place with numbers of shear pins, by applying a predetermined pressure to the annulus, the shear pin shear, the differential pressure is utilized to shift the sleeve and open the circulation ports, meanwhile a spring equipped will be compressed prepare to close the circulating sleeve once the annulus pressure released by spring force.

Technical parameter of Recloseable Circulating Valve

5”(127.5mm)

57mm

Length

758mm

Working Pressure

70Mpa(10000psi)

Tensile Strength

2550KN

Burst Pressure

127Mpa

Collapse Pressure

110Mpa

Torque Strength

60kN.m

Single Shear Pin Value

As Required

Working Temp.

-29oC~180oC

Service

H2S NACE MR0175(Above 175F)

Connection Thread

3 1/2” /EUE/IF Box Pin
